mirceateodor

Hello,

First of all sorry for my english. Please correct me if it is necesarry.
I want to present to you my OEM taillights with full LED and I quick method how to do them.



Steps :
1. By a OEM set of taillights and prepare them.

2. Cut them in the back (you can use a dremel tool or anything else to cut plastic openings). Also you have to break the colored lights lens (yellow and red) to have acces to the clear smoked plastic.


3. I made some carton templates.



4. By doing so I manage to cut the perforated circuit board more precise



5. After that I used adhesive metallic foil to cover the boards.



6. Then I mounted the LEDs.
(This was the 1 setup)


(For the 3 setup I used metallic bells. To have a better focus.


Difference :
without bells

with bells


7. For the sides I used plastic tubs because I did not have enough space to put the bells.


The Leds for them.

The result:

schulleno.1

*love it*
i want to buy them!!!!!!

Basti262

pretty cool!

mirceateodor

--- Pictures for the 1 setup ----











-------- Actual setup --------

After finding the right metallic bells I choosed a much more simple setup.

bamless

Nice! More pics please!

stormraider

Very very great, AWSOME... Thx for the quick and easy Tut bro...

I try to build them for my Tailights.

mirceateodor

Video :

ImageShack® - Online Photo and Video Hosting
ImageShack® - Online Photo and Video Hosting

Something that can help you.

LED series/parallel array wizard
LED series parallel array wizard

LED Info:
LED Advanced Technical Information

stormraider

Whats with the Cables? Do you need a resistor for the Leds?

Can you take a pic in Final Stad?

MisterPimp

Nice work dude and thx for the DIY

mirceateodor

Some Materials:

- perforated circuit board
- PVC pipe - approximately 13 mm diameter
- LEDs
*red-orange superflux/piranha (8x8mm, 0.20-30mA angle 80-90 degrees, 10,000 mcd)
Brake - 66 LEDs
Position - 98 LEDs
* superflux/piranha White (8x8mm, 0.20-30mA angle 80-90 degrees, 10,000 mcd)
reverse - 52 LEDs
* suerflux/piranha Yellow (8x8mm, 0.20-30mA angle 80-90 degrees, 10,000 mcd)
turn signal - 44 LEDs
- resistor : 560 ohms, 470 ohms.
- ceramic rezistor : 10 ohms * 17 W (better greater )
- self-adhesive aluminum foil
- metallic bells

For the yellow and red led I used 560 ohms rezistor
For the white ones I used 470 ohms.

You can find on the internet 2 setups for LED's and rezistors.

1 led + 1 rezistor(greater) @ 12V
3leds + 1 rezistor (smaller) @ 12 V

I choosed to use 1 setup because in case of a defect led or rezistor only the defect one will not work .
If you use 2 setup in case of defect led the whole group will not work.

Your choice.

1 setup :

2 setup :


Important .
But there is a "small" problem.

After completed the circuit board with all the leds and rezistor.
Only for Brake and Turn signal . you have to fool the your car because of the reduced power consumption you will have some errors.

You have to put in series a high power rezistor ( 35W>).
You can use ceramic rezistor or other type.

Little help :

http://forums.vwvortex.com/showthread.php?2766798/page3




Good luck.
In the near future , after I will finish my brother's OEM taillights (Golf 4 Variant), I will post some picture with more details. I hope.

Thx for U time.

Basti262

It´s a really, really great work!

basti535

Hey, you are from Sibiu! I will visit Sibiu and Cluj Napoca between christmas and New Years Eve!

Slacker

Thats really, really nice!!!!!!!!!!! i love the Audi style!!!!!!!!!

Werwolf13th

Great Job Solider Customstyle is the no.1 Style man!!!

Bulledge

Its a very good idea!And it looks great!

EnglischGolf

Very nice! Great Work!

Da könnten sich so manche Zubehörhersteller mal ne Scheibe von abschneiden!

golfiv19

richtig aber so isses leider nicht zugelassen und somit in D nicht fahrbar..... bei erwischen oder unfall könnte es teuer werden

EnglischGolf

Ja, das ist echt schade...Für Hella oder Inpro wäre es aber wahrscheinlich nicht so viel Arbeit, das Wissen ist da, die "Hüllen" sind da, die LED-Technik ist auch da.
Naja, in Deutschland müssen wir bei billigem und "geschmacksunterschiedlich" aussehendem Zubehör oder Original bleiben.

Finroder

Das heißt also allgemeiner Aufruf an die Hersteller von Rückleuchten - > Baut mal wieder was für uns kranke Golf 4 Liebhaber

EnglischGolf

Das funktioniert ja eh nicht, aber Hella und co hätten selbst mal drauf kommen können, bevor die die Originalen in grün, blau und was weiß ich noch rausgebracht haben.
